0818M- Insulated Slotted Screwdriver
0818M- Insulated Slotted Screwdriver
- Isolation tournevis pour vis à fente
- Izolowany śrubokręt płaski
- Isolierter Schlitzschraubendreher
- Alislado destornilladores
- مفك البراغي المعزول ذو النصل المسطح
- ไขควงปากแบนหุ้มฉนวน
- 一字絕緣避電螺絲起子
- VDE 1000V
- DIN 7437/ ISO 2380/ EN 60900
- Tip Made by SNCMVH Steel Material
Information
What is Insulated Hand Tool?
Insulated hand tool is a safety device that protects the user in case of an electrostatic shock. It offers protection against voltage 1,000 VAC or 1,500 VDC. All insulated hand tool must be marked with the year they were made and an official 1,000-Volt rating symbol.
IEC 60 900 is a universally recognized standard used to ensure that electrical testing tools are safe for use. DIN 60 900 is a German standard that requires manufacturers to test all electrical products for defects using an insulation resistance tester. VDE is an independent authority in Germany that has set the standards for testing and certifying electrical tools in the country.
| 0818M |  mm(inch) | SHAFT LENGTH mm | OVERALL LENGTH mm |  g |  pcs |
|---|---|---|---|---|---|
| M2-3 | 2.5(3/32) | 3*75 | 145 | 20 | 12 |
| M3-4 | 3.0(1/8) | 3*100 | 175 | 30 | 12 |
| M4-4 | 4.0(5/32) | 4*100 | 200 | 55 | 12 |
| M5-5 | 5.5(7/32) | 5*125 | 215 | 65 | 12 |
| M6-6 | 6.5(1/4) | 6*150 | 260 | 151 | 12 |
| M8-7 | 8 | 8*175 | 297 | 171 | 6 |
