1163M/A- Combination Wrench- 45° Offset
SKU
1163M/A
Categories Wrench- Individual, Wrench, Wrench / L-Key Wrench
Tags Combination Wrench, Offset, Wrench
1163M/A- Combination Wrench- 45° Offset- German Type
- Clés mixtes- 45° Offset
- Pochylenie klucza płasko-oczkowego 45°
- Maulschlüssel-Wölbung 45°
- Llaves combinada- 45° Offset
- مفاتيح ربط متعددة الاستخدامات، زاوية ° 45 .
- แคมเบอร์ประแจรวม 45°
- 德式輕薄柄, 兩用扳手彎度45°
- DIN 3113- ISO 3318, ISO 7738
- Wrench all we can support
1163M (mm) | W (mm) | W1 (mm) | T (mm) | T1 (mm) | L (mm) | g | pcs |
---|---|---|---|---|---|---|---|
6 | 17 | 12 | 4.8 | 6 | 115 | 24 | 12 |
7 | 17 | 12 | 4.8 | 6 | 115 | 24 | 12 |
8 | 19.5 | 13.2 | 5 | 6.3 | 125 | 32 | 12 |
9 | 21 | 15 | 5.2 | 6.5 | 130 | 40 | 12 |
10 | 21.5 | 16 | 5.8 | 6.5 | 136.4 | 46 | 12 |
11 | 23 | 18 | 5.8 | 7 | 146.2 | 52 | 12 |
12 | 25 | 19.5 | 6 | 7.5 | 156.2 | 66 | 12 |
13 | 28 | 20.5 | 6.3 | 8 | 166 | 76 | 12 |
14 | 30 | 22.5 | 6.9 | 9 | 175 | 96 | 12 |
15 | 33.5 | 25 | 7.2 | 10 | 195 | 126 | 12 |
16 | 33.5 | 25 | 7.2 | 10 | 195 | 126 | 12 |
17 | 36.5 | 27 | 7.6 | 11 | 215 | 172 | 12 |
18 | 36.5 | 27 | 7.6 | 11 | 215 | 177 | 12 |
19 | 40.5 | 29 | 8 | 11.5 | 235 | 218 | 12 |
20 | 40.5 | 29 | 8 | 11.5 | 235 | 218 | 12 |
21 | 43.5 | 32 | 8.5 | 12 | 255 | 234 | 12 |
22 | 46.5 | 33.5 | 9 | 12.5 | 270 | 284 | 12 |
23 | 46.5 | 33.5 | 9 | 12.5 | 270 | 284 | 12 |
24 | 49 | 35.5 | 9.5 | 13.2 | 285 | 352 | 6 |
25 | 52 | 37.5 | 10 | 14 | 300 | 404 | 6 |
26 | 52 | 37.5 | 10 | 14 | 300 | 404 | 6 |
27 | 56 | 40.5 | 10.5 | 14.5 | 320 | 462 | 6 |
28 | 56 | 40.5 | 10.5 | 14.5 | 320 | 462 | 6 |
29 | 60.5 | 44 | 11 | 15 | 340 | 525 | 6 |
30 | 60.5 | 44 | 11 | 15 | 340 | 525 | 6 |
32 | 64 | 46 | 11.5 | 15.5 | 365 | 635 | 6 |
1163A (inch) | W (mm) | W1 (mm) | T (mm) | T1 (mm) | L (mm) | g | pcs |
---|---|---|---|---|---|---|---|
(1/4) | 17 | 12 | 4.8 | 6 | 115 | 24 | 12 |
(5/16) | 19.5 | 13.2 | 5 | 6.3 | 125 | 32 | 12 |
(3/8) | 21.5 | 16 | 5.8 | 6.5 | 136.4 | 46 | 12 |
(7/16) | 23 | 18 | 5.8 | 7 | 146.2 | 52 | 12 |
(1/2) | 28 | 20.5 | 6.3 | 8 | 166 | 76 | 12 |
(9/16) | 30 | 22.5 | 6.9 | 9 | 175 | 96 | 12 |
(5/8) | 33.5 | 25 | 7.2 | 10 | 195 | 126 | 12 |
(11/16) | 36.5 | 27 | 7.6 | 11 | 215 | 172 | 12 |
(3/4) | 40.5 | 29 | 8 | 11.5 | 235 | 218 | 12 |
(13/16) | 43.5 | 32 | 8.5 | 12 | 255 | 234 | 12 |
(7/8) | 46.5 | 33.5 | 9 | 12.5 | 270 | 284 | 12 |
(15/16) | 49 | 35.5 | 9.5 | 13.2 | 285 | 352 | 6 |
(1") | 52 | 37.5 | 10 | 14 | 300 | 404 | 6 |
(1-1/16) | 56 | 40.5 | 10.5 | 14.5 | 320 | 462 | 6 |
(1-1/8) | 60.5 | 44 | 11 | 15 | 340 | 525 | 6 |
(1-1/4) | 64 | 46 | 11.5 | 15.5 | 365 | 635 | 6 |
