¼” 3⁄8″ ½” & ¾” Drive Micro Torque Wrench (Lock-up Setting)

Micro Torque Wrench (Lock-up Setting) ¼” 3⁄8″ ½” & ¾” Drive

  • Click-Type Micro Torque Wrench – Green Plastic Grip – ¼”, 3⁄8″, ½”, ¾” Drive
  • Clé dynamométrique à déclenchement – Poignée plastique verte – ¼” à ¾”
  • Klick-Drehmomentschlüssel – Grüner Kunststoffgriff – ¼” bis ¾” Antrieb
  • Llave dinamométrica tipo clic – Mango plástico verde – ¼” a ¾”
  • Chave de torque tipo clique – Cabo plástico verde – ¼” a ¾”
  • Klucz dynamometryczny klikowy – Uchwyt z zielonego plastiku – ¼”–¾”
  • Kattanós nyomatékkulcs – Zöld műanyag markolattal – ¼”–¾” hajtás
  • Klik-type momentsleutel – Groen plastic handvat – ¼” tot ¾”
  • Щелчковый динамометрический ключ – Зелёная пластиковая ручка – ¼”–¾”
  • مفتاح عزم طقة – مقبض بلاستيك أخضر – مقاسات من ¼” إلى ¾”
  • 點擊式微型扭力扳手 – 綠色塑膠握把 – 適用¼”至¾”驅動
  • 点击式微型扭力扳手 – 绿色塑料握柄 – 适用于¼”至¾”驱动
  • クリック式マイクロトルクレンチ – 緑のプラスチックグリップ – ¼”~¾”
  • 클릭형 마이크로 토크 렌치 – 녹색 플라스틱 손잡이 – ¼”~¾” 드라이브
  • ประแจแรงบิดไมโครแบบคลิก – ด้ามจับพลาสติกสีเขียว – ขนาด ¼” ถึง ¾”
  • Tıklamalı Mikro Tork Anahtarı – Yeşil Plastik Saplı – ¼”–¾”
    • Handle Introduction-Plier, Torque Wrench and Wrench
    • Plastic Green Handle
    • DIN EN ISO 6789
    • DIN 3120 – ISO 1174
    • Adjustable torque model for clockwise tightening.
      • The model applied on 1/4″, 3/8″ 1/2″, 3/4″ Drive, apply for N.m and ft lbs (Newton-metre, foot-pound)

Feature

  • Torque wrench is an essential tool for ensuring that bolts are tightened to the correct specification. They are made from chrome vanadium steel for strength and durability, and have a ratchet head that allows them to be used for clockwise or anti-clockwise torque. The handle is knurled for a good grip, and when the required torque setting is reached, the wrench produces an audible click and a slight release of tension.
  • Sensible and audible alarm on reaching preset torque value
Torque Wrench GN series Model
Clicker torque wrench
DRIVEITEM NO.CAPACITY
N · m
ITEM NO.CAPACITY
FT-LB
(INCH-LB)
L
mm / inch
porduct sizeicon1
g
¼"2170GN6-302170GI40-250
INCH · LB
290 / 13--¾"900扭力板手用小圖示
⅜"3170GN6-303170GI40-250
INCH · LB
295 / 13-¾"900扭力板手用小圖示
⅜"3171GN20-1103171GF15-80
FT · LB
380 / 15"1180扭力板手用小圖示
½"4170GN40-2104170GF30-150
FT · LB
535 / 21"2100扭力板手用小圖示
½4171GN70-3504171GF50-250
FT · LB
650 / 25-½"3110扭力板手用小圖示
¾"6170GN100-5006170GF50-300
FT · LB
865 / 34"4730扭力板手用小圖示
BLOW CASE FOR EACH
